June 11, 2020







TOKYO—Toshiba Electronic Devices & Storage Corporation ("Toshiba") has launched two lens reduction type 1,500-pixel monochrome CCD linear image sensors for industrial equipment: “TCD1105GFG,” with a built-in electronic shutter function, and “TCD1106GFG.” Sample shipment will start from July 2020.

The new sensors support two key industry requirements: faster operation of equipment that incorporate sensors, including inspection equipment with monochrome CCD linear image sensors; and lower power consumption.

The new sensors can be used at a maximum data rate of 25MHz, and both incorporate a timing generator circuit and CCD driver, realizing high-speed operation with few external circuits. A built-in sample and hold circuit lengthens the video output signal period, contributing to easier design for high-speed signal processing.

In addition to improved performance, lower power consumption than Toshiba’s current high-speed products is achieved with a single 3.3V power drive.

Features
・1,500 pixels, 25 MHz (max) data rate, monochrome CCD linear image sensors
・Built-in timing generator circuit reduces external driving circuits.
・Built-in sample and hold circuit extends video output signal period.
　(signal polarity: positive)
・Built-in electronic shutter function: TCD1105GFG only
・Single 3.3 V power drive



Applications
Automated optical inspection equipment, sensing equipment, barcode readers, etc.

Main Specifications



For more information on the new products, please visit:

TCD1105GFG
https://toshiba.semicon-storage.com/ap-en/semiconductor/product/linear-image-sensors/detail.TCD1105GFG.html?utm_source=chip1stop&utm_medium=webmedia&utm_campaign=jp&cid=jp-chip1stop


TCD1106GFG
https://toshiba.semicon-storage.com/ap-en/semiconductor/product/linear-image-sensors/detail.TCD1106GFG.html?utm_source=chip1stop&utm_medium=webmedia&utm_campaign=jp&cid=jp-chip1stop

*Company names, product names, and service names may be trademarks of their respective companies.
*Information in this document, including product prices and specifications, content of services and contact information, is current on the date of the announcement but is subject to change without prior notice.

Toshiba Electronic Devices & Storage Corporation’s Website＞

https://toshiba.semicon-storage.com/ap-en?utm_source=chip1stop&utm_medium=webmedia&utm_campaign=jp&cid=jp-chip1stop

Companies Website:
https://toshiba.semicon-storage.com/ap-en?utm_source=chip1stop&utm_medium=webmedia&utm_campaign=jp&cid=jp-chip1stop
