HW1Z-F2PQ4B IDEC Push Button Switch - 商品詳細情報

HW1Z-F2PQ4B

IDEC

Push Button Switch

Search Alternative Products

Show Similar

HW1Z-F2PQ4B

Product Overview

Non-illuminated Buzzer

Search Alternative Products

Show Similar

Product Overview

Non-illuminated Buzzer

Product Information

3D CAD情報
- SamacSys
Footprint/Symbol/3D CAD Information

Specifications

Manufacturer name: IDEC

Product name: HW1Z-F2PQ4B

Product classification: Push Button Switch

RoHS: RoHS

Series name: HW

Color: Black

Rated Voltage(DC): 12 to 24V

Size: Dia33.30mm

Other names: 1885-HW1Z-F2PQ4B

Isolation voltage: 30V

Mass: Around 17g

Mounting hole diameter: φ22

Operating temperature range: -20 to 50C

Operation type: Intermittent noise

Shape/Type: Non-illuminated type

Manufacturer Packaging: Bulk

Manufacturer packaging quantity: 1
