F971C105MAA Kyocera AVX Capacitor Tantalum Solid - 商品詳細情報
Search Alternative Products
Specifications
- Manufacturer name
- Kyocera AVX
- Product name
- F971C105MAA
- Product classification
- Capacitor Tantalum Solid
- Lifecycle Status
- Active
- RoHS
- RoHS
- Series name
- F97
- Case Code
- A
- Package
- 3216(1206inch)
- Electrical capacity
- 1uF
- Rated capacitance
- 1uF
- Tolerance
- 20%
- Rated Voltage(DC)
- 16V
- Type
- Molding
- Operating temperature range
- -55 to 125C
- Minimum category temperature
- -55°C
- Maximum category temperature
- +125°C
- ESR
- 7.5Ohm
- Mounting Type
- Surface Mount
- Size
- 3.2x1.6mm
- Length
- 3.2mm
- Width
- 1.6mm
- Height
- 1.2mm
- Automotive Authentication
- AEC-Q200
- Leakage current
- 0.5uA
- Feature
- Automotive/High Reliability
- Polarity
- Polar
- Feature
- Automobile|High Reliability
- Remarks
- AXV acquires the tantalum division of Nichicon
- Other names
- 478-8564-6 | 478-8564-2 | 478-8564-1
