ICE40UL1K-CM36AI Lattice Semiconductor FPGA - 商品詳細情報

ICE40UL1K-CM36AI

Lattice Semiconductor

FPGA

Search Alternative Products

Show Similar

ICE40UL1K-CM36AI

Lattice Semiconductor

FPGA

Lattice Semiconductor

FPGA

Product Overview

iCE40 UltraLite™, Low Cost Solution Form of iCE40 Family, 1.2V

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8542330001

Search Alternative Products

Show Similar

Product Overview

iCE40 UltraLite™, Low Cost Solution Form of iCE40 Family, 1.2V

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8542330001

Product Information

3D CAD情報
- SamacSys
- UltraLibrarian
Footprint/Symbol/3D CAD Information

Specifications

Manufacturer name: Lattice Semiconductor

Product name: ICE40UL1K-CM36AI

Product classification: FPGA

Lifecycle Status: Active

RoHS: RoHS

Package: 36-VFBGA

Series name: iCE40 UltraLite(TM)

RAM Bits: 57344

Supply voltage: 1.14 to 1.26V

Operating temperature range: -40 to 100C

Mounting Type: Surface Mount

I/O port: 26

Number of cells: 1248

LABs/CLBs: 156

Other names: 220-1958

Manufacturer Packaging: Tray

Manufacturer packaging quantity: 490

If you find an error in the product information, please let us know here.

Documents

Data Sheet
Datasheet	EN_Lattice Semiconductor_Datasheet_20180202024033798
Datasheet
Design and Simulation Data
Symbol/Footprint/3D Model(UltraLibrarian)	Download from Ultra Librarian
