ASE1D-2M-10-Z NIDEC COMPONENTS Slide Switch - 商品詳細情報

ASE1D-2M-10-Z

NIDEC COMPONENTS

Slide Switch

加工依頼

点击这里查看类似商品

ASE1D-2M-10-Z

产品概要

Switch Slide ON ON SPDT Top Slide 0.05A 48VAC 48VDC PC Pins Thru-Hole Plastic Pack

生命周期状态 : Active

ECCN : EAR99

HTSN : 8536509050

加工依頼

点击这里查看类似商品

产品概要

Switch Slide ON ON SPDT Top Slide 0.05A 48VAC 48VDC PC Pins Thru-Hole Plastic Pack

生命周期状态 : Active

ECCN : EAR99

HTSN : 8536509050

产品文档

3D CAD情報
- SamacSys
占用空间/符号/3D CAD信息

规格

制造商名称: NIDEC COMPONENTS

制品名: ASE1D-2M-10-Z

制品分类: Slide Switch

生命周期状态: Active

RoHS: RoHS

Series name: ASE

Rated current: 50mA

Rated Voltage(DC): 48V

Shape of the operation part: Top Slide

Contact point finish: Gold

Height: 10.8mm

Length: 9.5mm

Maximum service temperature: 85°C

Minimum service temperature: -20°C

Other names: 563-1151 | ASE1D2M10Z

Width: 5mm

Functional operation: ON ON

Maximum operating temperature: 85C

Minimum operating temperature: -20C

Type: Super-Miniature

原厂包装: Bulk

制造商数量: 25
