D2F-01L Omron Detector Switch - 商品詳細情報

D2F-01L

Omron

Detector Switch

代替品検索

類似スペック品検索

D2F-01L

製品概要

Switch Snap Action N.O./N.C. SPDT Hinge Lever PC Pins 0.1A 30VDC 0.78N Thru-Hole

ライフサイクル : 量産中

ECCN : EAR99

HTSN : 8536509040

代替品検索

類似スペック品検索

製品概要

Switch Snap Action N.O./N.C. SPDT Hinge Lever PC Pins 0.1A 30VDC 0.78N Thru-Hole

ライフサイクル : 量産中

ECCN : EAR99

HTSN : 8536509040

製品情報

3D CAD情報
- SamacSys
- UltraLibrarian
PCN/PDN(EOL)情報

製品仕様

メーカ名: Omron

製品名: D2F-01L

製品分類: Detector Switch

ライフサイクル: 量産中

シリーズ名: D2F

操作部形状: Hinge Lever

作動力: 0.78

サイズ: 12.8X6.5X5.8mm

その他の型番/品番: D2F-01L(UL/CSA) | SW154 | Q2505549 | D2F01L | D2F01LULCSA

幅: 5.8mm

長さ: 13.95mm

高さ: 11.5mm

動作寿命: Cycles

定格電圧(DC): 30V

定格電流: 100mA(DC)

機能動作: N.O./N.C.

メーカ荷姿: Bulk

メーカ梱包数量: 1000

製品情報に誤りがございましたら、こちらからご指摘ください。

製品説明

【特長】
・基板実装にも適した極超小形サイズ（高さ6.5×幅12.8×奥行5.8MM）
・高精度、2枚ばねの反転機構により高耐久性を実現
・インサート端子を用い、ケース下面に段差を設けることなどにより、フラックスの浸入を防止
・プリント基板用端子は自立端子、右アングル端子、左アングル端子も用意。ハンダづけ端子も新形状を品揃え

【用途】
・家電機器、音響機器、事務機器、通信機器など幅広い用途に使用可能

製品情報

データシート
データシート(English)	EN_Omron_Datasheet_20150227125014297
データシート(English)	EN_Omron_Datasheet_20180312172336492
証明書
RoHS指令適合証明書	RoHS compliance status / Non-inclusion certificate check & download
設計・シミュレーション用データ
シンボル/フットプリント/3Dモデル(UltraLibrarian)(English)	Download from Ultra Librarian
