Manufacturer name

Renesas Electronics

Product name

R5F1006AASP#30

Product classification

Microcontrollers

Lifecycle Status

LTB

RoHS

RoHS

Number of bits

16

Core

RL78

Speed

32MHz

FLASH

4KB

ROM

4kx8

RAM

2KB

I/O port

16

Peripheral (Ethernet)

No

Package

20-LSSOP

Interface

CSI/I2C/UART/USART

Other names

-1161-R5F1006AASP#30

10-Bit A/D Converter (ch)

6ch

10-Bit D/A Converter (ch)

0ch

12-Bit A/D Converter (ch)

0ch

12-Bit D/A Converter (ch)

0ch

12-Bit Timer (ch)

1ch

14-Bit A/D Converter (ch)

0ch

16-Bit A/D Converter (ch)

0ch

16-Bit D/A Converter (ch)

0ch

16-Bit Timer (ch)

8ch

24-Bit Sigma-Delta A/D Converter (ch)

0ch

2D Drawing Engine

No

32-Bit High Res Timer (ch)

0ch

32-Bit Timer (ch)

0

8-Bit D/A Converter (ch)

0ch

8-Bit Timer (ch)

4ch

ADC

10bitX6ch

Accelerator

No

Analog Comparator (ch)

0ch

Asynchronous General Purpose Timer

0ch

Asynchronous General Purpose Timer / Interval Timer (ch)

1ch

Bit Length

16

CAN

0ch

CAN-FD (ch)

0ch

CPU

RL78

CPU Architecture

RL78

Camera I/F (Parallel)

No

Capacitive Touch Sensing Unit (ch)

0ch

Category 2

RL78 Low Power 8 & 16-bit MCUs

Class

IC

DMA

Yes

DMA (ch)

2ch

DMAC or DTC

DMAC

DRAM I/F

No

DTC (ch)

No

Data Converters

A/D 6x8/10b

Data Flash

4KB

Debug Interface

Single wire serial

Delta-Sigma A/D Converter

No

ECC SRAM

No

EPC

PLSP0020JC

Easy to Start

-

EtherCat (ch)

0ch

Ethernet

No

Ethernet ch

0ch

Ethernet speed

N/A

External Interrupt Pins

3

External Memory Bus (bit)

No

Family Name

RL78

Floating Point Unit

No

GPU

No

Graphics LCD Controller

No

Group Name

G13

High Resolution Output Timer

0

High-Speed Analog Comparator (ch)

0ch

I2C

2

I3C (ch)

0ch

Image Codec

No

IrDA(yes/no)

No

LIN

0

LVD or PVD

Yes

Length

6.65mm

Low-Power Analog Comparator (ch)

0ch

MIPI Interfaces (CSI) (ch)

0ch

MIPI Interfaces (DSI/CSI)

0

Main CPU

RL78-S2

Mounting Type

Surface Mount

Number of Supply Voltage(s)

1

OPAMP (ch)

0ch

OSPI (ch)

0ch

On-chip Oscillator

Yes

Operating Freq(Max)

32MHz

Operating Voltage

1.6 to 5.5V

Operating temperature range

-40 to 85C

Original supplier name/brand name

renesas

Oscillator Type

内蔵

PCI Express (generation and ch)

0

PGA (ch)

0ch

PWM Output (pin#)

2ch

Peripherals

DMA/LVD/POR/PWM/WDT

Pitch

0.65mm

Power-On Reset

Yes

Program Memory

16KB

Program Memory Size

16kB(16Kx8)

Program Memory Type

Flash

QSPI (ch)

0ch

RTC

Yes

SCI or UART (ch)

2ch

SDHI (ch)

0ch

SPI

0

SPI (ch)

2ch

SSI

0ch

Security & Encryption

No

Segment LCD Controller

No

Series name

RL78/G1x

Size

6.65X6.1X1.4mm

Standby operable timer

No

Sub CPU

No

Sub-clock (32.768 kHz)

No

Supply voltage

1.6 to 5.5V

Temperature Sensor (ch)

1

Thickness

1.4mm

Timer

12bitX1ch|16bitX8ch

Tx Current

Tx Current

Type

LSSOP

UART

2

USB FS (host ch/device ch)

(0/0)

USB HS (host ch/device ch)

(0/0)

USB Ports

0

USB SS (host ch/device ch)

(0/0)

USBFS

0ch

USBHS

0ch

Watchdog Timer (ch)

1

Width

6.1mm

Wireless

No

Manufacturer Packaging

Tray

Manufacturer packaging quantity

1920
