Manufacturer name

Renesas Electronics

Product name

R9A07G075M24GBG#AC0

Product classification

Microcontrollers

Lifecycle Status

Active

RoHS

RoHS

Number of bits

32

Core

Cortex-R52x2

Speed

800MHz

RAM

2048KB

I/O port

194

Peripheral (USB)

Yes

Peripheral (Ethernet)

Yes

Package

0

Other names

-1161-R9A07G075M24GBG#AC0 | 559-R9A07G075M24GBG#AC0

10-Bit A/D Converter (ch)

0ch

12-Bit A/D Converter (ch)

24ch

12-Bit D/A Converter (ch)

0ch

12-Bit Timer (ch)

0ch

14-Bit A/D Converter (ch)

0ch

16-Bit A/D Converter (ch)

0ch

16-Bit Timer (ch)

14ch

32-Bit High Res Timer (ch)

0ch

32-Bit Timer (ch)

20ch

8-Bit D/A Converter (ch)

0ch

8-Bit Timer (ch)

0ch

ADC

12bitX24ch

Accelerator

-

Asynchronous General Purpose Timer

0ch

CAN

2ch

CAN-FD (ch)

0ch

CPU

Cortex-R52 x 2

Capacitive Touch Sensing Unit (ch)

0ch

Category 2

RZ 32 & 64-bit MPUs

Class

IC

DMA

Yes

DRAM I/F

SDRAM,OctaRAM (8-bit),HyperRAM (8-bit)

DTC (ch)

No

Data Flash

0KB

Delta-Sigma A/D Converter

No

Display Function Remarks

Display Function: No

EPC

PLBG0320GC

EtherCat (ch)

0ch

Ethernet

10/100M/1G x 3 ch

Ethernet Remarks

Gigabit Ethernet: 2ch or 1ch

Ethernet ch

3ch

Family Name

RZ

GPU

-

Group Name

T2M

High-Speed Analog Comparator (ch)

0ch

Human Machine Interface

-

I2C

3

I3C (ch)

0ch

IrDA(yes/no)

No

Length

17mm

Low-Power Analog Comparator (ch)

0ch

Main CPU

Cortex-R52 x 2

Operating Freq(Max)

800MHz

Operating Voltage

3.135 to 3.465V

Operating temperature range

-40 to 125C

Original supplier name/brand name

renesas

PCI Express (generation and ch)

-

PLP

2032-08-01

PWM Output (pin#)

0ch

Pitch

0.8mm

Program Memory

0KB

RTC

No

SCI or UART (ch)

0ch

SPI

4

SSI

0ch

Security & Encryption

No

Series name

RZ/T

Size

17X17X1.4mm

Sub CPU

-

Supply voltage

3.135 to 3.465V

Thickness

1.4mm

Timer

16bitX8ch|32bitX18ch|16bitX6ch|32bitX2ch

Type

LFBGA

UART

6

USB

USB2.0 x 1 ch (1H/F/OTG)

USBFS

0ch

USBHS

1ch

Watchdog Timer (ch)

2ch

Width

17mm

Wireless

0

Manufacturer Packaging

Tray

Manufacturer packaging quantity

90
