100YXF10MEFC6.3X11 Rubycon Capacitor Aluminum - 商品詳細情報

100YXF10MEFC6.3X11

Rubycon

Capacitor Aluminum

Search Alternative Products

Show Similar

100YXF10MEFC6.3X11

Product Overview

Cap Aluminum Lytic 10uF 100V 20% (6.3 X 11mm) Radial 2.5mm 140mA 5000h 105C Bulk

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8532220020

Search Alternative Products

Show Similar

Product Overview

Cap Aluminum Lytic 10uF 100V 20% (6.3 X 11mm) Radial 2.5mm 140mA 5000h 105C Bulk

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8532220020

Product Information

Data sheet
3D CAD情報
- SamacSys
- UltraLibrarian
Footprint/Symbol/3D CAD Information

Specifications

Manufacturer name: Rubycon

Product name: 100YXF10MEFC6.3X11

Product classification: Capacitor Aluminum

Lifecycle Status: Active

RoHS: RoHS

Series name: YXF

Package: CAN(Radial)

Electrical capacity: 10uF

Rated capacitance: 10uF

Tolerance: 20%

Rated Voltage(DC): 100V

Operating temperature range: -40 to 105C

Minimum operating temperature: -40C

Maximum operating temperature: 105C

Purpose: General Purpose

Size: 6.3mm

Width: 2.5mm

Height: 12.5mm

Diameter: 6.3mm

Product lifetime: 5000h

Polarity: Polar

Leakage current: 0.01CV or 3uA, whichever is greater (after 2 minutes)

Impedance: 1.2Ohm

Ripple Current @ Low Frequency: 58.8mA(120Hz)

Ripple Current @ High Frequency: 140mA(100kHz)

Pitch: 2.5mm

Mounting Type: Through hole

Other names: 1189-3675-2 | 1189-3675-1-ND | 1189-3675-2-ND | 1189-3675-3-ND | 1189-3675-1 | 100YXF10MEFC6.3X11-ND | 1189-3675-1INACTIVE | 1189-3675

Manufacturer Packaging: Bulk

Manufacturer packaging quantity: 2000

If you find an error in the product information, please let us know here.

Documents

Data Sheet
Datasheet	EN_Rubycon_Datasheet_20140617022445683
Design and Simulation Data
Symbol/Footprint/3D Model(UltraLibrarian)	Download from Ultra Librarian
