10YXF1000M10X16 Rubycon Capacitor Aluminum - 商品詳細情報

10YXF1000M10X16

Rubycon

Capacitor Aluminum

Search Alternative Products

Cross-reference information

Show Similar

10YXF1000M10X16

Product Overview

Cap Aluminum Lytic 1000uF 10V 20% (10 X 16mm) Radial 5mm 770mA 6000h 105C Bulk

Lifecycle Status : Obsolete

ECCN : EAR99

HTSN : 8532220020

Search Alternative Products

Cross-reference information

Show Similar

Product Overview

Cap Aluminum Lytic 1000uF 10V 20% (10 X 16mm) Radial 5mm 770mA 6000h 105C Bulk

Lifecycle Status : Obsolete

ECCN : EAR99

HTSN : 8532220020

Product Information

3D CAD情報
- SamacSys
- UltraLibrarian
Footprint/Symbol/3D CAD Information

Specifications

Manufacturer name: Rubycon

Product name: 10YXF1000M10X16

Product classification: Capacitor Aluminum

Lifecycle Status: Obsolete

RoHS: RoHS

Series name: YXF

Package: CAN(Radial)

Electrical capacity: 1000uF

Rated capacitance: 1000uF

Tolerance: 20%

Rated Voltage(DC): 10V

Type: Electrolytic

Minimum operating temperature: -40C

Maximum operating temperature: 105C

Size: φ10.00X16.00mm

Length: 16mm

Height: 16mm

Diameter: 10mm

Product lifetime: 6000h@105C

Ripple current: 770mA

Leakage current: 100uA@2Min

Ripple Current @ High Frequency: 770mA@100kHz

Manufacturer packaging quantity: 1000

If you find an error in the product information, please let us know here.

Documents

Data Sheet
Datasheet	EN_Rubycon_Datasheet_20150203184602145
Datasheet	EN_Rubycon_Datasheet_20180312191814573
Design and Simulation Data
Symbol/Footprint/3D Model(UltraLibrarian)	Download from Ultra Librarian
