CFM-5015V-258-330 Same Sky (formerly CUI Devices) Blowers and Fans - 商品詳細情報

CFM-5015V-258-330

Same Sky (formerly CUI Devices)

Blowers and Fans

Search Alternative Products

Show Similar

CFM-5015V-258-330

Same Sky (formerly CUI Devices)

Blowers and Fans

Same Sky (formerly CUI Devices)

Blowers and Fans

Product Overview

24 V, 51 mA, 50 x 50 x 15 mm, Dc Fan

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8414596590

Search Alternative Products

Show Similar

Product Overview

24 V, 51 mA, 50 x 50 x 15 mm, Dc Fan

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8414596590

Product Information

Specifications

Manufacturer name: Same Sky (formerly CUI Devices)

Product name: CFM-5015V-258-330

Product classification: Blowers and Fans

Lifecycle Status: Active

Frame size: 50X50mm

Rated Voltage(DC): 24V

Other names: 102-4367

Airflow: 17CFM

Bearing Type: omniCOOL™

Current-maximum: 51mA

Dimension: 50, 50, 15mm

Fan Type: Axial Fan

Height: 15mm

Length: 50mm

Maximum operating temperature: 70°C

Maximum static pressure: 0.23Pa

Minimum operating temperature: -10°C

Operating Voltage: 27.6, 8Vdc

Rated Voltage: 24Vdc

Rated speed: 6100RPM

Series name: CFM-50V, CFM-50V

Sound pressure level: 33dBA

Static Pressure: 0.23inH2O

Thickness: 15mm

Width: 50mm

If you find an error in the product information, please let us know here.

Details

Click here for 3D Model

Documents

Data Sheet
Datasheet	EN_Same Sky (formerly CUI Devices)_Datasheet_20200305122021822
Certificate
Other Compliance	EN_Same Sky (formerly CUI Devices)_Other Compliance_20250204210035075
Certificate of RoHS Compliance	EN_Same Sky (formerly CUI Devices)_Certificate of RoHS Compliance_20250204204256986
Design and Simulation Data
Symbol/Footprint/3D Model	EN_Same Sky (formerly CUI Devices)_Symbol/Footprint/3D Model_20250204181714154
