3613C101K  TE Connectivity  Inductor Surface Mount  -  商品詳細情報

3613C101K

TE Connectivity

Inductor Surface Mount

3613C101K TE Connectivity

The images are for reference only. For the precise specifications, refer to the product specifications.

Added to bookmarks.

    • Search Alternative Products

    3613C101K

    3613C101K

    TE Connectivity

    Inductor Surface Mount

    TE Connectivity

    Inductor Surface Mount

    Added to bookmarks.
    • Product Overview

    Inductor Chip Molded/Unshielded Wirewound 100uH 10% 796KHz 40Q-Factor Ferrite 110mA 8Ohm DCR 1812 T/R

    Lifecycle Status : Active
    ECCN : EAR99

    HTSN : 8504508000

    Search Alternative Products

    Product Overview

    Inductor Chip Molded/Unshielded Wirewound 100uH 10% 796KHz 40Q-Factor Ferrite 110mA 8Ohm DCR 1812 T/R

    Lifecycle Status : Active
    ECCN : EAR99

    HTSN : 8504508000

    Product Information

    Related Videos
    Data sheet
    Design/Simulation Data
    Other Documents
    Data Sheet
    Datasheet

    Specifications

    Manufacturer name
    TE Connectivity
    Product name
    3613C101K
    Product classification
    Inductor Surface Mount
    Lifecycle Status
    Active
    RoHS
    RoHS
    Inductance
    100uH
    Inductance tolerance
    10%
    Rated current
    110mA
    Q-value
    40@796kHz
    Self-Resonant Frequency
    8MHz
    Inductance Frequency -Test
    796kHz
    Height
    3.4mm
    Length
    4.5mm
    Width
    3.2mm
    Purpose
    Chip
    Maximum service temperature
    100°C
    Minimum service temperature
    100°C
    Other names
    16240942 | 1624094-2 | 2266-3613C101KTR | A102544TR | 1624094-2-ND | A102544DKR | A102544CT
    Maximum operating temperature
    100C
    Minimum operating temperature
    -30C
    Tolerance
    10%

    If you find an error in the product information, please let us know here.
