THPM4301A THine Electronics DC/DC Switching Regulators - 商品詳細情報

THPM4301A

THine Electronics

DC/DC Switching Regulators

加工依頼

点击这里查看类似商品

THPM4301A

THine Electronics

DC/DC Switching Regulators

THine Electronics

DC/DC Switching Regulators

生命周期状态 : 量产中

ECCN : EAR99

HTSN : 8542900000

加工依頼

点击这里查看类似商品

生命周期状态 : 量产中

ECCN : EAR99

HTSN : 8542900000

产品文档

数据表
3D CAD情報
- SamacSys
占用空间/符号/3D CAD信息

数据表
规格书(English)	EN_THine Electronics_Datasheet_20201006175930227

规格

制造商名称: THine Electronics

制品名: THPM4301A

制品分类: DC/DC Switching Regulators

生命周期状态: 量产中

RoHS: 符合RoHS2标准

开关形式: Step-down(Buck)

类型: Power Module

输出数: 1

Output Power: 2.95V

最大输入电压: 6V

输出电压: 0.6 to 3.6V

输入电压: 2.95 to 6V

动作温度范围: -40 to 85C

输出电压精度: 1%

封装: 56pin LGA

输出电流: 0 to 6A

原厂包装: Tape & Reel

制造商数量: 250

如果产品信息中有错误，请在此处指出。
