Start Production; the NJG1186, FEM for 1.2-GHz-band GNSS

2022/07/12Nisshinbo Micro Devices RF/微波

- Contribute to the realization of high-precision GNSS -

May 31, 2022

Nisshinbo Micro Devices Inc. will start producing the NJG1186, a front-end module (FEM) for high-precision GNSS, including GPS, GLONASS, BeiDou, and Galileo in May.

The NJG1186 includes a pre-SAW filter and a low noise amplifier (LNA) and covers 1.2-GHz band supporting L5/E5/B2/G3/L2C bands (1164 MHz to 1228 MHz). Please refer to Figure 1.

Figure 1. Operating Frequency

In recent years, the number of equipment that requires high-precision location information, such as automobiles, drones, and wearable devices, has been increasing. For high-precision positioning, it is necessary to have multi-band capability to receive signals of 1.2-GHz band in addition to the conventional 1.5-GHz band.

Since GNSS is installed in a variety of equipment, it is expected to be used in a variety of environments. Therefore, there are several requirements for different environments, such as high humidity resistance for outdoor use, and space saving for small equipment.

We will further add FEM products for high-precision GNSS to our products lineup to meet these requirements.

For reference, the NJG1186-A, an AEC-Q100 grade 2 and VDA 6.3 compliant version of this product, will be produced in August.

Please be refered below News Release.

https://www.nisshinbo-microdevices.co.jp/en/about/info/20220531.html
