About Snapdragon
Quaclomm’s Snapdragon is a high-performance
chipset installed on many smartphones of
Android and Windows Phone.
Previously, Snapdragon, which was mainly used for
smartphones, can now be used for various devices in the IoT market.
We provide various support with its use.
· Long-term supply of products
· Global supply system
· Expansion of peripheral devices for evaluation
· Hardware & software development ecosystems
· Provision of mass production board tailored to your application
· Technical support for development
Features of Snapdragon™ 410E
The Snapdragon 410E that is currently available, is manufactured using 28nm process and uses the quad core of the Cortex-A53 processor.
Cortex-A53 improves energy efficiency per core and performance per power consumption by lowering the frequency and saving power, and it can be expected to reduce battery consumption. Furthermore, the Snapdragon 410 is compatible with 13 million-pixel cameras and can play 1080p HD videos by using the evolution version of Ardeno 305, the “Adreno 306” GPU.
The Snapdragon 410E can greatly contribute to the development of devices to be introduce into the IoT market, so please be sure to consider installing it in devices for new products and succession devices.
Configuration of Snapdragon™ 410E
The Snapdragon™ 410E chipset consists of the following 4 chips.
■APQ8016 Qualcomm® Snapdragon™ 410E Processor
・ARM Cortex A53 quad-core, supports 32-bit/64-bit, 1.2GHz
・Qualcomm® Adreno 306 GPU, 400MHz
・OpenGL, DirectX, content protection
・28nm LP CMOS, 14.0mm x 12.0mm x 0.96mm, 760-pin NSP
■PM8916 Power Management IC
・Equipped with audio codec
・65nm RF CMOS, 6.2mm x 6.2mm x 0.86mm, 176-pin WB-NSP
WCN3620 WiFi Bluetooth Combo Chip
Integrating three different wireless connection technologies into a single device 3.32 × 3.55 × 0.63 mm, it is a highly integrated IC design using a 16-pin wafer level nanoscale package (61 WLCSP).
It also uses a low power consumption 65 nm RF CMOS manufacturing technology that is optimal for battery-powered devices where power consumption and performance are important.
・IEEE802.11b/g/n 2.4GHz
・Bluetooth 4.1/4.0BLE
・65nm RF CMOS, 3.32mm x 3.55mm x 0.63mm, 61 pin WLNSP
WGR7640 GPS Receiver
・GPS
・GNSS (global navigation satelite services)
・BeiDou
・COMPASS
・65nm RF CMOS, 2.07mm ｘ 1.51mm ｘ 0.63 mm, 17-pin WLNSP
Application examples of Snapdragon™ 410E
Snapdragon 410E is ideal for embedded applications that require low power consumption, high performance, and low heat generation.
Application examples:
・Business displays
・Surveillance cameras
・Smart homes
・Digital media and TV Dongle
・Robotics
・Digital signage
・Various battery-powered applications
