TOKYO— Toshiba Electronic Devices & Storage Corporation today announced the launch of “SSM6N357R,” a new MOSFET with a built-in diode between the drain and gate terminals. The device is suited to driving inductive loads, such as mechanical relays. Volume shipments start today.

SSM6N357R integrates a pull-down resistor, a series resistor and a Zener diode, which reduces the parts count and save on board space. Furthermore, since it is a dual-type package product (2 in 1), it has an approximately 42% smaller mounting area than the alternative of using two SSM3K357R (2.4 x 2.9 x 0.8 mm) single-type package products.

An industry-standard TSOP6F-class package, a low operating voltage of 3.0V and AEC-Q101 qualification make the SSM6N357R suitable for automotive and many other applications.



Applications
・Relay and solenoid control for automotive applications
・Relay and solenoid control for industrial applications
・Clutch control for OA equipment

Features
・Reduced board space and part count (pull-down resistor, series resistor and Zener diode integrated.)
・Low operating voltage of 3.0 V
・Dual package (2 in 1)
・AEC-Q101 qualified



Main Specifications

Equivalent Circuits



Follow the link below for more on TDSC’s latest small low-on-resistance MOSFETs.
