7826-0000PR 3M PCB to cable connector - 商品詳細情報

7826-0000PR

PCB to cable connector

Search Alternative Products

Show Similar

7826-0000PR

PCB to cable connector

Product Overview

Conn IDC Connector HDR 26 POS 2.54mm Solder RA Thru-Hole Box

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8536694040

Search Alternative Products

Show Similar

Product Overview

Conn IDC Connector HDR 26 POS 2.54mm Solder RA Thru-Hole Box

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8536694040

Product Information

Data sheet
3D CAD情報
- SamacSys
Footprint/Symbol/3D CAD Information

Data Sheet
Datasheet	EN_3M_Datasheet_20141104173009369

Specifications

Manufacturer name: 3M

Product name: 7826-0000PR

Product classification: PCB to cable connector

Lifecycle Status: Active

RoHS: RoHS

Contact point finish: Gold Over Nickel

Height: 7.3mm

Length: 38.1mm

Maximum operating temperature: 105C

Maximum service temperature: 105°C

Minimum service temperature: -55°C

Number of arrays: 2

Number of poles: 26

Pitch: 1.27mm

Product type: ヘッダー

Rated current: 1A

Shape/Type: Right angle

Type: IDC Connector

Width: 7mm

Wire connection method: IDT
