AS1D-2M-10-Z NIDEC COMPONENTS Slide Switch - 商品詳細情報

AS1D-2M-10-Z

NIDEC COMPONENTS

Slide Switch

Search Alternative Products

Show Similar

AS1D-2M-10-Z

Product Overview

Switch Slide ON ON SPDT Top Slide 0.05A 48VAC 48VDC 0.4VA PC Pins Thru-Hole

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8536509050

Search Alternative Products

Show Similar

Product Overview

Switch Slide ON ON SPDT Top Slide 0.05A 48VAC 48VDC 0.4VA PC Pins Thru-Hole

Lifecycle Status : Active

ECCN : EAR99

HTSN : 8536509050

Product Information

3D CAD情報
- SamacSys
Footprint/Symbol/3D CAD Information

Specifications

Manufacturer name: NIDEC COMPONENTS

Product name: AS1D-2M-10-Z

Product classification: Slide Switch

Lifecycle Status: Active

RoHS: RoHS

Series name: AS

Rated current: 50mA(AC/DC)

Shape of the operation part: Top Slide

Height: 12.3mm

Length: 9.5mm

Maximum service temperature: 85C

Minimum service temperature: -20C

Other names: 563-1579 | AS1D-2M-10-Z-ND

Width: 5mm

Functional operation: ON/ON

Manufacturer Packaging: Tray

Manufacturer packaging quantity: 25
