September 30, 2013





TOKYO—Toshiba Corporation (TOKYO: 6502) today announced the launch of load switch ICs embedded with reverse current blocking circuits[1] that offer an ON resistance of 18.4mΩ[2], the industry's lowest[3]. The ICs are suited for use as power management switches in smartphones, tablets, Ultrabooks™ and other mobile devices. Samples shipment starts from today with mass production scheduled for spring 2014.

The new products, the TCK20xG series, achieve low ON resistance and low operating voltage in a 0.9×0.9mm ultra compact package by adopting Toshiba's newly developed CMOS process and unique analog circuit design techniques. As smartphones, tablets, Ultrabooks and other mobile devices require longer battery hours, lighter weight and smaller size, there is increase in demand for ultra-compact, low power consumption, low power dissipation switches.

Toshiba will increase its line-up of compact, high performance load switch IC to meet the requirements of the rapidly increasing mobile equipment market, with devices suitable for other markets also in the pipeline.

Applications
Power management switches for smartphones, tablets, Ultrabooks™ and other mobile devices.

Key Features

■Low on resistance: 18.4mΩ

■Low voltage operation: 0.75V

■Low standby current: 0.6µA[4]

■Reverse current blocking circuit

■Ultra small package: WCSP4C（0.9mm × 0.9mm, t:0.5mm)

■Variety of function options (Inrush current reduction, auto discharge, etc.)

Main specifications



[1] A circuit that prevents flow of current towards the input pin when output pin voltage is larger than the input pin voltage.
[2] Sample typical value under the conditions of Input voltage: 0.75V, Output current: -1.5A, room temperature.
[3] Silicon semiconductor CMOS IC devices under 1×1mm as of September 30, 2013. Toshiba survey.
[4] Sample typical value under the conditions of Input voltage: 3.6V, room temperature during standby.

 * Ultrabook™ is a registered trademark of Intel Corporation in the United States and/or other countries.

Information in this document, including product prices and specifications, content of services and contact information, is current on the date of the announcement but is subject to change without prior notice.

Toshiba Corporation- Semiconductor and Storage Products Company　Website＞http://www.semicon.toshiba.co.jp/eng/index.html?mm=cp1001&no=06
