Toshiba’s 80V N-channel Power MOSFETs Fabricated with Latest Generation Process Help Improve Power Supply Efficiency
2020/04/01Toshiba
电源/电力
- Expanding line-up of U-MOS X-H power MOSFET series -
March 30, 2020
TOKYO— Toshiba Electronic Devices & Storage Corporation (“Toshiba”) has added 80V N-channel power MOSFETs to its “U-MOS X-H series” fabricated with the latest generation process. The new MOSFETs are suitable for switching power supplies in industrial equipment used in data centers and communication base stations.
The expanded line-up includes "TPH2R408QM," housed in SOP Advance, a surface-mount type packaging, and "TPN19008QM," housed in a TSON Advance package. Shipments starts today.
Drain-source On-resistance in the new 80V U-MOS X-H products, manufactured with the latest generation process, is approximately 40% lower than that of 80V products in the current generation process U-MOS Ⅷ-H series products. The trade-off between the drain-source On-resistance and the gate charge characteristics[1] has also been improved[2] by optimizing device structure. As a result, the new products feature industry’s lowest[3] power dissipation.
Toshiba is expanding its lineup of products that reduce power dissipation to help cut equipment power consumption.
Applications
・Switching power supplies (High efficiency AC-DC converters, DC-DC converters, etc.)
・Motor control equipment (Motor drive, etc.)
Features
・The industry’s lowest[3] power dissipation (by improving the trade-off between On-resistance and gate charge characteristic[2])
・Industry’s lowest level[3] On-resistance:
RDS(ON)=2.43mΩ (max) ＠VGS=10V (TPH2R40QM)
RDS(ON)=19mΩ (max) ＠VGS=10V (TPN19008QM)
・High channel temperature rating : Tch=175℃
Main Specifications
(Unless otherwise specified, @Ta=25℃)
Notes:
[1] Total gate charge (gate-source plus gate-drain), gate switch charge, output charge
[2] Compared with TPH4R008NH (U-MOS Ⅷ-H series), TPH2R408QM has improved its drain-source On-resistance x total gate charge by approximately 15%, drain-source On-resistance x gate switch charge by approximately 10%, and drain-source On-resistance x output charge by approximately 31%.
[3] As of March 30, 2020, Toshiba survey.
