A8L-21-15N3 Omron Power switch - 商品詳細情報

A8L-21-15N3

Omron

Power switch

代替品検索

類似スペック品検索

A8L-21-15N3

製品概要

Switch Rocker ON OFF DPST Quick Connect Curved Rocker 10A 250VAC 50000Cycles Box

ライフサイクル : 量産中

ECCN : EAR99

HTSN : 8536509065

代替品検索

類似スペック品検索

製品概要

Switch Rocker ON OFF DPST Quick Connect Curved Rocker 10A 250VAC 50000Cycles Box

ライフサイクル : 量産中

ECCN : EAR99

HTSN : 8536509065

製品情報

3D CAD情報
- SamacSys
PCN/PDN(EOL)情報

製品仕様

メーカ名: Omron

製品名: A8L-21-15N3

製品分類: Power switch

ライフサイクル: 量産中

RoHS: RoHS対応

定格電流: 10A(AC)

その他の型番/品番: 39-A8L-21-15N3

メーカ荷姿: Bulk

メーカ梱包数量: 300

製品情報に誤りがございましたら、こちらからご指摘ください。

製品説明

【特長】
・高容量開閉用のロッカースイッチ
・独自の開閉機構で耐突入電流100Aを実現
・切れ味が良く、ソフトな操作感触
・ワンタッチ取りつけが可能
・接点ギャップ3MM以上
・UL、CUL規格取得、EN規格適合品

【仕様】
・定格：125VAC 10A（抵抗負荷、ランプ負荷）、125VAC 8A（誘導負荷、電動機負荷）、250VAC 10A（抵抗負荷、ランプ負荷）、250VAC 8A（誘導負荷、電動機負荷）

製品情報

データシート
データシート(English)	EN_Omron_Datasheet_20180216122842105
データシート	JA_Omron_データシート_20220120140920489
証明書
RoHS指令適合証明書	RoHS compliance status / Non-inclusion certificate check & download
